DMX-25-150-900-E1A1 |
|
| Dimming interface: | DMX512/RDM |
| Dimming range: | 0~100%, LED start at 0.1% possible. |
| Input voltage: | 200-240Vac |
| Efficiency: | >84% |
| Current Accuracy: | ±3% |
| Output voltage: | 10-54VDC |
| CC output: | 150mA-900mA |
| Output power: | 1.5W~25W |
| working temperature: | tc: 80°C ta: -30°C ~ 55°C |
| Dimension: | 167×39×30mm(L×W×H) |
| Package Size: | 168×41×32mm(L×W×H) |
| Weight (G.W): | 160g |
