With over 20 years of deep expertise in smart lighting control, LTECH has built a strong technological foundation. It took the lead in developing the Matter series of smart lighting control products. The LTECH Matter controller enables multi-ecosystem interconnection via the Matter protocol, delivering versatile lighting solutions. It is compatible with major smart home platforms including Apple Home, Google Home, Amazon Alexa, and Samsung SmartThings, and also supports voice control.
| Wireless Protocol: | Matter over WiFi |
| Channels: | 1CH |
| Operating Voltage: | 100-240V~，50/60Hz |
| Output Current: | Max. 10A |
| Rated Load: | Max.5A/CH (Capacitive/Inductive); Max.10A/CH (Resistive) |
| Load Inrush Current: | Max.70A@10ms |
| Operating Temp.: | -10°C~40°C |
| Input Type: | Momentary Switch, Rocker Switch |
| Compatible Loads/Devices: | Lighting, Home Appliances, Fans |
| Dimensions: | L39.5xW33xH18(mm) |
| Package Size: | L43xW58xH25(mm) |
| Weight: | 25±5g |
| Wireless Protocol: | Matter over WiFi |
| Channels: | 2CH |
| Operating Voltage: | 100-240V~，50/60Hz |
| Output Current: | Max. 16A(2 Channels Total) |
| Rated Load: | Max.5A/CH (Capacitive/Inductive); Max.10A/CH (Resistive) |
| Load Inrush Current: | Max.70A@10ms |
| Operating Temp.: | -10°C~40°C |
| Input Type: | Momentary Switch, Rocker Switch |
| Compatible Loads/Devices: | Lighting, Home Appliances, Door Locks, Fans |
| Dimensions: | L45xW39.4xH18(mm) |
| Package Size: | L49xW64xH25(mm) |
| Weight: | 35±5g |
| Wireless Protocol: | Matter over WiFi |
| Operating Voltage: | 100-240V~，50/60Hz |
| Dimming Type: | Triac/ELV |
| Output Current: | Max.2A |
| Load Inrush Current: | Max.60A |
| Rated Load: | Max.400W@240V~(Resistive load), LED:Max.200W@240V~ |
| Operating Temp.: | -10°C~40°C |
| Input Type: | Momentary Switch, Rocker Switch |
| Compatible Loads Devices: | Incandescent, Halogen, LED Lamps |
| Dimensions: | L45xW39.4xH18(mm) |
| Package Size: | L49xW64xH25(mm) |
| Weight: | 30±5g |
| Wireless Protocol: | Matter over WiFi |
| Channels: | 2CH |
| Operating Voltage: | 100-240V~，50/60Hz |
| Output Current: | Max. 1.5A |
| Relay Inrush Current: | 70A@10ms |
| Operating Temp.: | -10°C~40°C |
| Input Type: | Momentary Switch, Rocker Switch |
| Compatible Loads Devices: | Curtains, Blinds ,Up-and-down rolling door |
| Dimensions: | L39.5xW33xH18(mm) |
| Package Size: | L43xW58xH25(mm) |
| Weight: | 25±5g |
| Wireless Protocol: | Matter over WiFi |
| Channels: | 1CH |
| Operating Voltage: | 100-240V~，50/60Hz, 12V⎓/24-48V⎓ |
| Output Current: | Max.5A |
| Rated Load: | Max.2A(Capacitive/nductive); Max.5A(Resistive) |
| Relay Inrush Current: | 70A@10ms |
| Operating Temp.: | -10°C~40°C |
| Compatible Input Devices: | Momentary Switch, Rocker Switch |
| Dimensions: | L39.5xW33xH18(mm) |
| Package Size: | L43xW58xH25(mm) |
| Weight: | 24±5g |
| Wireless Protocol: | Matter over WiFi |
| Operating Voltage: | 100-240V~,50/60Hz |
| Operating Temp.: | -10°C~40°C |
| Control Commands: | Press/Double Press/Press and Hold |
| Compatible Input Devices: | Supports up to 4-gang Momentary Switch |
| Dimensions: | L45xW39.4xH18(mm) |
| Package Size: | L49xW64xH25(mm) |
| Weight: | 23±5g |
| Input Signal: | Matter over Thread |
| Channels: | 5CH |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | RGB Max.15A 5A/CH CW Max.10A |
| Load Power: | 180W@12V 360W@24V 540W@36V 720W@48V |
| Service Life: | 100000 Hours |
| Supported Platform: | Apple Home, Google Home, Amazon Alexa, Amazon Alexa, SmartThings and all smart home platforms supporting the standard Matter protocol. |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L91×W37×H21(mm) |
| Weight(G.W.): | 46g |
| Input Signal: | Matter over Thread |
| Channels: | 2CH |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | 10A/CH@12V 10A/CH@24V 9A/CH@36V 9A/CH@48V |
| Load Power: | 120W@12V 240W@24V 324W@36V 432W@48V |
| Service Life: | 100000 Hours |
| Supported Platform: | Apple Home, Google Home, Amazon Alexa, Amazon Alexa, SmartThings and all smart home platforms supporting the standard Matter protocol. |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L91×W37×H21(mm) |
| Weight(G.W.): | 46g |
| Input Signal: | Matter over Thread |
| Channels: | 1CH |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | 10A@12V 10A@24V 10A@36V 10A@48V |
| Load Power: | 120W@12V 240W@24V 360W@36V 480W@48V |
| Service Life: | 100000 Hours |
| Supported Platform: | Apple Home, Google Home, Amazon Alexa, Amazon Alexa, SmartThings and all smart home platforms supporting the standard Matter protocol. |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L91×W37×H21(mm) |
| Weight(G.W.): | 46g |
| Wireless Protocol: | Matter over Thread |
| Switch channel: | 2CH |
| Operating voltage: | 100-240V~,50/60Hz,μ |
| Max. load current of the relay: | 10A |
| Load parameters: | Resistive load: 1000W@230Vac/CH, 500W@110Vac/CH, Max.2000W Capacitive load: 400W@230Vac/CH, 200W@110Vac/CH, Max.800W |
| Relay surge current: | 70A@10ms |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L45xW45.5xH20.5(mm) |
| Weight(G.W.): | 42g |
| Wireless Protocol: | Matter over Thread |
| Switch channel: | 1CH |
| Operating voltage: | 100-240V~,50/60Hz,μ |
| Load parameters: | Resistive load: 1000W@230Vac, 500W@110Vac, Capacitive load: 400W@230Vac, 200W@110Vac |
| Relay surge current: | 70A@10ms |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L45xW45.5xH20.5(mm) |
| Weight(G.W.): | 38g |
