LTECH Intelligent dimmable led driver have excellent performance:

  • Fully Digital circuit design, excellent performance and long working life
  • PWM digital dimming, maintain the best LED’s CRI(color rendering index)
  • Standard logarithmic dimming curve, the human eye visual feel more comfortable
  • 60000:1 wide dimming range, 0-100% full dimming range,LED start at 0.1% possible
  • Power factor>0.99, Efficiency>86%, THD(Total Harmonic Distortion)<10%
  • Short circuit / Over-temperature /Over load protection
  • Current consistent in multi LED driver working, balanced light
  • Class 2 security isolation power supply
  • Compliant with SELV(Safety Extra Low Voltage) standard



CV 0/1-10V Driver
  • 150W 24VDC CV 0-10V/1-10V Driver
    Model AD-150-24-F1M1
    Dimming interface 0-10V 1-10V 10VPWM  OR PUSH DIM
    Dimming range 0-100%
    Input voltage 100-240VAC
    Power factor  >0.99
    Efficiency >93%
    Output voltage 24VDC
    Output power 150W
    Output current 6.25A
  • 150W 12VDC CV 0/1-10V Driver
    Model AD-150-12-F1M1
    Dimming interface 0-10V 1-10V 10VPWM  OR PUSH DIM
    Dimming range 0-100%
    Input voltage 100-240VAC
    Power factor  >0.99
    Efficiency >91%
    Output voltage 12VDC
    Output power 150W
    Output current 12.5A
  • 36W 24VDC CV 0/1-10V Driver
    Model: AD-36-24-F1P1
    Dimming interface 0-10V 1-10V 10VPWM  OR PUSH DIM
    Dimming range: 0-100% LED Startup Current<0.1%
    Input voltage 100-240VAC
    Efficiency >85%
    Output voltage  24VDC
    Output power 36W
    Output current 1.5A
  • 36W 12VDC CV 0/1-10V Driver
    Model: AD-36-12-F1P1
    Dimming interface 0-10V 1-10V 10VPWM  OR PUSH DIM
    Dimming range: 0-100% LED Startup Current<0.1%
    Input voltage 100-240VAC
    Efficiency >85%
    Output voltage  12VDC
    Output power 36W
    Output current 3A
  • 75W 24VDC CV 0/1-10V LED Driver
    Model AD-75-24-F1M1
    Dimming interface 0-10V 1-10V 10VPWM  OR PUSH DIM
    Dimming range 0-100%
    Input voltage 100-240VAC
    Power factor  >0.99
    Efficiency >86%
    Output voltage 24VDC
    Output power 75W
    Output current 3.1A
  • 75W 12VDC CV 0/1-10V LED Driver
    Model AD-75-12-F1M1
    Dimming interface 0-10V 1-10V 10VPWM  OR PUSH DIM
    Dimming range 0-100%
    Input voltage 100-240VAC
    Power factor  >0.99
    Efficiency >86%
    Output voltage 12VDC
    Output power 75W
    Output current 6.2A
