16CH DMX-PWM Decoder LT-880-350

  • Description
  • Video
  • Download

LT-880-350 16CH DMX-PWM Decoder

Input signal DMX512
Input power DC12V~DC48V
Output voltage DC3V~DC42V
Max load current 350mA ×16CH
Output power 1.05W~14.7W×16CH  Max 235.2W
DMX512 socket XLR-3, Green terminal (with signal amplification function)
Dimming range 0~100%
Working temperature -30℃~65℃
Dimension L260×W123×H42mm
Package Size L268×W127×H44mm
Weight (G.W) 950g
